Niobium Disc | High Purity Niobium Metal Disc Supplier
- High-purity niobium metal disc with purity ≥99.9%
- Manufactured to ASTM B393 standard
- Available in R04200 (Nb1), R04210 (Nb2), R04251 (Nb-1Zr), and R04261 grades
- Melting point 2477°C — the fourth-highest among all elements
- Density 8.57 g/cm³ with excellent dimensional stability
- Outstanding corrosion resistance to acids, alkalis, and most chemical media
- Superior superconducting properties for particle accelerator and MRI applications
- Low neutron absorption cross-section for nuclear applications
Description Of Niobium Disc
Niobium Disc is a high-purity niobium metal disc manufactured from pure niobium (UNS R04200/R04210) to ASTM B393 standard. Niobium is a silver-grey refractory metal with a melting point of 2477°C, excellent corrosion resistance, and superior superconducting properties. These discs are widely used as sputtering targets, in nuclear reactors, and in superconducting applications.
Niobium offers a unique combination of properties that make it ideal for demanding applications. With a melting point of 2477°C (the fourth-highest among all elements, after tungsten, tantalum, and rhenium), niobium discs can withstand extreme temperatures. The material also offers outstanding corrosion resistance to acids, alkalis, and most chemical media, and it has superior superconducting properties, making it suitable for particle accelerators and MRI applications.
High purity niobium discs are available in custom diameters and thicknesses, with surface finishes including machined, polished, and annealed. Typical applications include sputtering targets for thin film deposition, nuclear reactor components, superconducting materials, and high-temperature assemblies.
Features Of Niobium Disc
High Purity: Purity ≥99.9%, ensuring minimal contamination in critical applications.
ASTM B393 Compliant: Manufactured to ASTM B393 standard for niobium and niobium alloy strip, sheet, and plate.
Multiple Grades Available: R04200 (Nb1), R04210 (Nb2), R04251 (Nb-1Zr), R04261.
High Melting Point: 2477°C, the fourth-highest among all elements.
Excellent Corrosion Resistance: Resists acids, alkalis, and most chemical media.
Superior Superconducting Properties: Critical for superconducting accelerators and MRI applications.
Low Neutron Absorption: Suitable for nuclear reactor applications.
Customizable Dimensions: Custom diameters and thicknesses available.
Surface Finishes: Machined, polished, annealed.
ISO 9001 Certified: Full traceability and quality assurance.
Specifications Of Niobium Disc
| Parameter | Specification |
|---|---|
| Material | Niobium (Nb) |
| UNS Designation | R04200 (Nb1), R04210 (Nb2), R04251 (Nb-1Zr), R04261 |
| Standard | ASTM B393 |
| Purity | ≥99.9% |
| Density | 8.57 g/cm³ |
| Melting Point | 2477°C |
| Boiling Point | 4744°C |
| Young's Modulus | 105 GPa |
| Thermal Conductivity | 5.37 W/(m·K) |
| Thermal Expansion | 7.3 µm/(m·K) |
| Diameter Range | Customizable |
| Thickness Range | Customizable |
| Surface Finish | Machined, polished, annealed |
| Product Standard | ASTM B393 |
| Certification | ISO 9001 |
