Zirconium Rod & Bar | Zr702 UNS R60702 ASTM B550 Supplier
- High-purity zirconium and zirconium alloy rod and bar
- Available in Zr702 (UNS R60702), Zr704 (UNS R60704), Zr705 (UNS R60705)
- Manufactured to ASTM B550 / ASME SB-550 standard
- Outstanding corrosion resistance in hydrochloric, sulfuric, nitric, and organic acids
- Immune to stress corrosion cracking (SCC); high resistance to pitting and crevice corrosion
- Low neutron absorption cross-section — ideal for nuclear applications
- Excellent formability, weldability, and machinability
- Diameters from 6mm to 150mm, custom sizes available
- Surface finishes: pickled, machined, polished
- Direct supplier with ISO 9001 certified manufacturing
- Ideal for chemical processing, nuclear reactors, heat exchangers, and medical devices
Description Of Zirconium Rod & Bar | Zr702 UNS R60702 ASTM B550 Supplier
Zirconium Rod & Bar are solid cylindrical or rectangular products manufactured from zirconium and zirconium alloys through vacuum arc remelting (VAR), forging, hot rolling, cold finishing, and precision machining. As a direct ASTM B550 zirconium rod supplier, we produce these materials in unalloyed zirconium grades Zr702 (UNS R60702) and Zr704 (UNS R60704), as well as zirconium-niobium alloy Zr705 (UNS R60705). These materials offer a unique combination of properties that make them indispensable in the most demanding environments.
Zirconium possesses outstanding corrosion resistance in hydrochloric acid, sulfuric acid, nitric acid, acetic acid, and strong alkalis. It is immune to stress corrosion cracking (SCC) and highly resistant to pitting and crevice corrosion. Its low thermal neutron absorption cross-section makes it the material of choice for nuclear reactor components. Additionally, zirconium has good formability and weldability, allowing it to be machined, bent, and welded into complex shapes.
Our zirconium rods and bars are available in diameters from 6mm to 150mm, with custom sizes upon request. Surface finishes include pickled, machined, and polished. The material complies with ASTM B550 / ASME SB-550, the standard specification for zirconium and zirconium alloy bar and wire. Typical applications include chemical processing equipment, nuclear reactors, heat exchangers, condensers, reaction vessels, piping, pumps, valves, medical devices, and aerospace components. We are a direct supplier with ISO 9001 certified manufacturing, offering full traceability and competitive pricing.
Features Of Zirconium Rod & Bar | Zr702 UNS R60702 ASTM B550 Supplier
High Purity: Zr + Hf ≥ 99.2% for Zr702 and Zr704; Zr + Hf ≥ 95.5% for Zr705, ensuring consistent performance.
ASTM B550 Compliant: Manufactured to ASTM B550 / ASME SB-550 standard for zirconium bar and wire.
Excellent Corrosion Resistance: Resists hydrochloric acid, sulfuric acid, nitric acid, acetic acid, and strong alkalis. Immune to stress corrosion cracking.
Low Neutron Absorption: Low thermal neutron absorption cross-section for nuclear applications.
Good Formability: Can be machined, bent, and welded into complex shapes.
Good Weldability: Can be welded using TIG and electron beam welding in inert gas atmospheres.
High Melting Point: 1852°C (Zr702) and 1840°C (Zr705) for high-temperature applications.
Low Density: 6.51 g/cm³ (Zr702) and 6.64 g/cm³ (Zr705), lighter than steel and many refractory metals.
Low Thermal Expansion: Ensures dimensional stability under thermal cycling.
Customizable Dimensions: Diameters 6–150mm, custom lengths and surface finishes available.
Direct Supplier: ISO 9001 certified manufacturing with full traceability and competitive pricing.
Specifications Of Zirconium Rod & Bar | Zr702 UNS R60702 ASTM B550 Supplier
| Parameter | Specification |
|---|---|
| Material | Zirconium and zirconium alloy |
| Grades | Zr702 (R60702), Zr704 (R60704), Zr705 (R60705) |
| Standard | ASTM B550 / ASME SB-550 |
| Purity (Zr + Hf) | ≥ 99.2% (Zr702, Zr704); ≥ 95.5% (Zr705) |
| Hafnium Content | ≤ 4.5% |
| Density | 6.51 g/cm³ (Zr702/Zr704); 6.64 g/cm³ (Zr705) |
| Melting Point | 1852°C (Zr702); 1840°C (Zr705) |
| Thermal Conductivity | ~22 W/(m·°C) |
| Elastic Modulus | 99.3 GPa (Zr702) |
| Tensile Strength | ≥380 MPa (Zr702); ≥413 MPa (Zr704); ≥552 MPa (Zr705) |
| Yield Strength | ≥205 MPa (Zr702); ≥241 MPa (Zr704); ≥379 MPa (Zr705) |
| Elongation | ≥16% (Zr702); ≥14% (Zr704); ≥16% (Zr705) |
| Diameter Range | 6 – 150 mm (customizable) |
| Length | Customizable |
| Surface Finish | Pickled, machined, polished |
| Product Standard | ASTM B550 / ASME SB-550 |
| Certification | ISO 9001 |
