Beryllium Dome Window | High Purity Be X-Ray Window
- High-purity beryllium dome window with 99.9% purity (3N grade)
- Hemispherical dome design with flange for vacuum sealing
- Low density 1.848 g/cm³ — ideal for X-ray window applications
- High X-ray transmissivity for low-energy X-ray detection
- Excellent vacuum tightness with leak rate < 3×10⁻¹⁰ mbar·L/s
- Superior strength-to-weight ratio and corrosion resistance
- Ideal for X-ray detectors, synchrotron beamlines, and medical imaging
- Custom sizes and flange configurations available per customer requirements
- Surface finishes: machined, polished, vacuum-tight
Description Of Beryllium Dome Window
Beryllium Dome Window is a high-purity beryllium metal window in a hemispherical dome shape, specifically designed for X-ray and vacuum applications. Beryllium is a lightweight, silver-grey metal with a density of 1.848 g/cm³, excellent X-ray transmissivity, and superior mechanical strength. The dome shape with flange allows for direct mounting into vacuum chambers and X-ray detector systems.
Beryllium offers a unique combination of properties that make it ideal for X-ray window applications. With low density and low atomic number (Z=4), beryllium provides high transmissivity for low-energy X-rays, minimizing spectral contamination and improving detection sensitivity. The material also offers high strength even in thin sections, excellent vacuum tightness, and good thermal stability. The dome geometry provides additional structural rigidity and allows for a larger viewing area compared to flat windows.
High purity beryllium dome windows are available in custom sizes and flange configurations, with surface finishes including machined, polished, and vacuum-tight. Typical applications include X-ray detectors (EDXRF, WDXRF, XRD), synchrotron beamlines, medical imaging systems, and vacuum systems.
Features Of Beryllium Dome Window
High Purity: 99.9% purity (3N grade), ensuring minimal spectral contamination in X-ray analysis.
Dome Design: Hemispherical dome shape with flange for vacuum sealing and structural rigidity.
Low Density: 1.848 g/cm³, enabling high X-ray transmissivity for low-energy detection.
Excellent Vacuum Tightness: Leak rate < 3×10⁻¹⁰ mbar·L/s for reliable vacuum isolation.
High Strength: Superior mechanical strength even in thin sections.
Corrosion Resistance: Resists moisture, solvents, and many chemicals.
Customizable Dimensions: Custom sizes and flange configurations available.
Surface Options: Machined, polished, vacuum-tight.
ISO 9001 Certified: Full traceability and quality assurance.
Specifications Of Beryllium Dome Window
| Parameter | Specification |
|---|---|
| Material | Beryllium (Be) |
| Purity | ≥99.9% (3N grade) |
| Density | 1.848 g/cm³ |
| Melting Point | 1277°C |
| Boiling Point | 2970°C |
| Young's Modulus | 287 GPa |
| Thermal Conductivity | 2.01 W/cm/K |
| Thermal Expansion | 11.3 µm/(m·K) |
| Electrical Resistivity | 4.0 µΩ·cm |
| Shape | Dome / Hemispherical with flange |
| Dimensions | Customizable |
| Surface Finish | Machined, polished, vacuum-tight |
| Certification | ISO 9001 |
